Leica Stellaris Confocal

A high-speed, laser scanning confocal with fluorescence lifetime and super-resolution capabilities. For access please contact micron@bioch.ox.ac.uk.


Specifications


  • DMi8 CS Premium, inverted motorised microscope stand
  • Epi-fluorescence lamp and filters for eye piece viewing
  • Transmitted light detector for brightfield/DIC/POL
  • Motorized DIC
  • Lasers: 405 nm and White Light Laser, 485 nm – 790 nm
  • 5 confocal fluorescence detectors (HyD S: photon counting, detection up to 850
    nm)
  • 8 kHz Tandem scanner
  • FRAP, FRET capabilities
  • Super Z galvo stage (inserts: universal, petri dish, multi-well)
  • Adaptive Focus Control (Hardware Autofocus)
  • TauSense tools for lifetime-based contrast, gating, separation, FRET
  • LAS X Navigator for multi-position, multi-region and overview imaging
  • Navigator Expert and Autonomous Microscopy (for AI based rare event detection)
  • Lightning Super Resolution (improves resolution to 120 nm in xy, 200 nm in z)
  • Aivia Go image analysis
  • Objectives – 5x, 10x, 20x, 20x multi-immersion, 63x oil


Access to Micron User Guides (requires Oxford SSO)

User Guides

White Light Laser

How the White Light Laser works

Confocal imaging of a kidney section

3D rendered movie of a kidney section captured using a Leica confocal microscope.  Alexa Fluor® 488 wheat germ agglutinin is a fluorescent lectin that labels the glomeruli and convoluted tubules (cyan). Actin located in glomeruli and the brush border are stained with Alexa Fluor® 568 phalloidin (magenta), nuclei are stained with the  DNA stain DAPI (grey).
